European-Style Adjustable-Base Double-Sided Rack

Customization available for material configuration, dimensions, and colors.

Core Advantages

Space utilization – The double-sided open design allows simultaneous access from both sides of the aisle. Each side can be operated independently, increasing storage density within the same floor area.

Access convenience – With no vertical columns obstructing either side, operators or forklifts can access goods directly from both sides, shortening travel paths and improving picking efficiency.

Floor adaptability – Adjustable feet with threaded lifting mechanisms independently compensate for minor unevenness on concrete, epoxy, or hardened floors, eliminating the need for floor anchors or secondary leveling.

Structural rigidity – Uprights are cold-formed with integrated stiffening ribs. Shelves on both sides are connected through beams and column bolts to form a symmetrical, stable frame, resisting lateral thrust and torsional deformation under load.

Coating durability – Electrostatic powder coating provides adhesion meeting cross-cut test requirements, with corrosion and scratch resistance. Color stability is maintained under indoor environmental conditions.

Customization flexibility – Material thickness, overall dimensions, shelf spacing and quantity, and finish color can be adjusted based on item specifications and storage plans, with production made to order.

Product Features

    Dimensions: 1000 mm (L) × 800 mm (W) × 2200 mm (H)

    Surface finish: Electrostatic powder coating (color options available)

    Primary materials: Cold-rolled steel (uprights and shelves), square tube (beams and connectors)

    Manufacturing processes: Laser cutting, bending, spot welding, grinding, electrostatic powder coating, etc.

    Configuration: Double-sided open structure with shelves on both sides

    Base structure: Adjustable leveling feet (20–50 mm compensation range per foot, threaded adjustment)

    Suitable environment: Indoor warehousing and retail environments, normal temperature and humidity conditions

    Customization: Overall dimensions, column wall thickness, number and spacing of shelves, powder coating color

Application Scenarios

    Industrial warehousing – Dual-side categorized storage of medium-sized components, case-packed materials, and finished goods in central warehouse areas.

    Supermarkets and retail stores – Aisle-side display and restocking management of bagged food items, bottled beverages, and daily necessities.

    Logistics sorting centers – Dual-side temporary storage and rapid sorting of totes, parcels, and assorted goods.

    Wholesale and retail outlets – Double-sided display of small to medium-sized merchandise to maximize display capacity per unit area.

FAQ & Precautions

Frequently Asked Questions

    What is the maximum compensation range of the adjustable feet?

    Each foot provides a threaded adjustment range of 20–50 mm. If floor height differences exceed this range, partial floor leveling is recommended prior to rack installation to ensure upright verticality and overall load stability.

    What is the maximum load capacity per shelf level?

    Load capacity depends on column cross-section dimensions, material thickness, and beam span. Under the standard 1000 mm length configuration, each tier supports 80–120 kg under uniformly distributed load. It is recommended to provide unit item weight and total storage quantity during customization for manufacturer load calculation.

    Is the double-sided rack suitable for placement in the center of an aisle?

    Yes. The double-sided design is optimized for central aisle or warehouse center placement, with both sides accessible independently without mutual interference.

    Do the adjustable feet require maintenance after long-term use?

    It is recommended to inspect the foot threads and locking nuts every 6–12 months. If the rack is to be relocated, raise the feet off the ground before moving, and re-level after repositioning to prevent thread damage during dragging.

Precautions

    During installation, adjust each leveling foot to achieve solid floor contact and verify the rack verticality with a spirit level to prevent structural deformation or localized overloading caused by suspended feet.

    When storing items on both sides, distribute weight evenly across the shelves to avoid tilting caused by overloading on one side.

    Before relocating the rack, raise all leveling feet off the ground. Re-level and lock the nuts after repositioning to prevent thread damage during dragging.

    If the coating becomes scratched or chipped, apply rust-preventive treatment promptly to prevent substrate oxidation and corrosion in humid environments.
