Placemat Display Hook — Extra-Thick, Rust-Resistant, and Durable

Custom made

Core Advantages

    Extra-thick construction – Material: carbon steel wire (diameter 5.0 to 7.0 mm) or carbon steel plate (thickness 3.0 to 4.0 mm). Compared to standard hooks (diameter 3.0 to 4.0 mm), cross-sectional area increases by 100% to 200%, with a proportional increase in bending stiffness.

    Rust resistance – Surface finish options: hot-dip galvanizing or epoxy powder coating. Hot-dip galvanized layer thickness: 50 to 80 microns, suitable for humid environments. Powder coating thickness: 80 to 100 microns, available in black, white, and silver gray.

    Wide-span design – Horizontal section length range: 150 to 300 mm, accommodating placemats with unfolded widths of 200 to 400 mm. J-shaped uptilted tip (15 to 30 degrees) prevents placemats from sliding off. Horizontal sections can feature an anti-slip texture or a rubber sleeve to increase the friction coefficient.

    Mounting methods – Two mounting types available: slatwall insert (fits standard 12.7 mm slot width) and bolt-on type (mounting plate with 2 or 4 mounting holes, diameter 6 to 8 mm).

Product Features

    Material – Q235B carbon structural steel, wire, or plate.

    Material specifications – Round bar diameter: 5.0, 6.0, 7.0 mm; or flat bar thickness 3.0, 4.0 mm, width 15 to 25 mm.

    Horizontal section length – 150, 200, 250, 300 mm (from front of vertical section to tip).

    Vertical section height – 80 to 150 mm, depending on mounting type.

    Tip uptilt – J-shaped tip, uptilt angle options: 15, 20, 25, 30 degrees; uptilt height: 10 to 20 mm.

    Surface finish – Hot-dip galvanizing (zinc layer thickness 50-80 microns) or epoxy powder coating (black, white, silver gray, coating thickness 80-100 microns).

    Mounting types:

        Type A: Slatwall insert, insertion depth 35 mm, with anti-lift locking tab

        Type B: Wall/post bolt-on, mounting plate size 50×50 mm, with 2×Φ8 mm holes

        Type C: Shelf beam clamp type, fits beam thickness 1.5-3.0 mm

    Per-hook load capacity – 3 to 8 kg, decreasing with horizontal length. 150 mm: 6-8 kg; 200 mm: 5-7 kg; 250 mm: 4-6 kg; 300 mm: 3-5 kg.

    Per-hook capacity (quantity) – 5 to 15 placemats, depending on thickness and folding method. For folded bundles, each bundle thickness not exceeding 30 mm.

    Accessory options – Rubber anti-slip sleeve (length 100-150 mm), removable tip ball stop, label holder (clips to vertical section).

Application Scenarios

    Placemat, table runner, and tea towel are displayed in home goods stores.

    Folded towel and dishcloth hanging display in supermarket textile sections.

    Fabric placemats and embroidered tablecloths are displayed in gift shops.

    Textile sample hanging on trade show display racks.

    Bundled placemat hanging storage in warehouses (for easy access).

Frequently Asked Questions and Precautions

Frequently Asked Questions

Q: How to determine the appropriate horizontal section length?
A: Horizontal section length should be at least half the unfolded width of the placemat. Measure the fully unfolded placemat width and divide by two as a baseline reference. Example: A 400 mm width placemat requires a horizontal length of at least 200 mm. For folded bundles, the length should exceed half the bundle thickness. Add 20 to 30 mm to the calculated value as a retention margin.

Q: What is the anti-slip difference between J-shaped uptilt and straight hooks?
A: The J-shaped uptilt creates a mechanical stop; folded placemat edges or hanging loops are trapped behind the uptilt root and cannot slide off. Larger uptilt angles provide stronger anti-slip but may make loading larger placemats more difficult. Straight hooks (no uptilt) rely on tip ball stops or rubber sleeves for friction-based anti-slip, suitable for lightweight placemats (single-piece weight under 200 grams).

Q: What is the specific rust resistance difference between hot-dip galvanizing and powder coating?
A: Hot-dip galvanizing creates a metallurgical bond between zinc and the steel substrate, providing cathodic protection. If the coating is scratched, the surrounding zinc corrodes preferentially, protecting the steel. Powder coating is an organic coating; when scratched, the exposed steel begins rusting immediately. In humid environments (relative humidity above 80%) or areas with potential moisture exposure, hot-dip galvanizing is recommended. In dry indoor environments, powder coating meets rust protection requirements.

Precautions

    Do not exceed the per-hook load rating for the corresponding length. Individual placemats are typically lightweight (50-200 grams), but cumulative weight from excessive quantities may exceed the rating.

    When hanging placemats, center them on the horizontal section to maintain balanced weight distribution. Hanging off-center causes the hook to tilt toward the heavier side, causing placemats to slide and accumulate on one side.

    Before installation, verify the load capacity of the mounting surface. For slatwall mounting, the slatwall's own load rating may be lower than the hook's capacity; always use the lower rating.

    Inspect hook levelness and mounting point tightness monthly. Address bending deformation or loose bolts promptly.

    Clean with a dry cloth. Use neutral detergent on galvanized surfaces. Avoid abrasive cleaning tools on powder-coated surfaces.

    Rubber anti-slip sleeves may harden or crack after extended use (12 to 18 months). Replace sleeves if the function is compromised.

    This hook is not intended for hanging wet placemats. Moisture accelerates coating aging, and water may seep into mounting points, causing corrosion.
