Perforated back panel with accessories, premium single-sided display shelf

Core Advantages

    Vertical space utilization – 2400mm height with multiple adjustable shelf levels increases display tiers per floor area.

    Accessory compatibility – The perforated back panel features hole spacing compatible with standard hooks, shelf brackets, and end caps, supporting hanging displays or featured product highlighting.

    Structural strength – Manufactured with heavy‑gauge cold‑rolled steel and square tube frames. Each shelf level is rated for heavier items such as cooking oil, beverages, and bottled water, resisting permanent bending or deformation.

    Narrow single-sided profile – 480mm depth occupies minimal aisle space, suitable for small retail areas or as a supplementary display unit.

    Ventilation – The perforated back allows gradual air circulation through the shelf, reducing dust accumulation and moisture behind products.

    Customization – Length, number of tiers, color, perforation density, and stiffener placement can be adjusted per order.

Product Features

    Dimensions: 3000 mm (L) × 480 mm (W) × 2400 mm (H)

    Surface finish: Powder coating (color options available)

    Primary materials: Cold‑rolled steel (heavy‑gauge), wire, square tube

    Manufacturing processes: Laser cutting, bending, spot welding, grinding, powder coating

    Back panel type: Perforated sheet metal (uniform hole pattern), compatible with standard hooks and shelf brackets

    Shelf type: Multiple adjustable tiers (solid or wire mesh options, with edge stiffeners)

    Accessory compatibility: Shelves, hooks, end caps, price tag strips (purchased separately or customized)

    Customization: Overall dimensions, number and spacing of shelves, perforation diameter and pitch, color

Application Scenarios

    Supermarket wall‑lining sections – displaying bagged foods, beverages, daily chemical products

    Convenience store single‑aisle areas – showcasing small packaged goods and promotional items

    Pharmacies and beauty stores – hanging small items on hooks while placing boxed products on shelves

    Promotional end caps or new product zones – using end caps and hooks for limited‑time offers

FAQ & Precautions

Frequently Asked Questions

    What is the difference between a perforated back panel and a wire mesh back panel?
    A perforated back panel is made from a solid metal sheet with punched holes, providing a continuous flat surface suitable for magnetic accessories or price labels. A wire mesh back panel is constructed from woven or welded wires, offering higher airflow. This product uses a perforated back panel.

    What is the load capacity per shelf?
    Capacity depends on shelf thickness, number of stiffeners, and span (3000mm). Under typical configurations with uniform distribution, each shelf supports 60-100kg. It is recommended to confirm actual load ratings with the manufacturer.

    Are hooks included?
    The standard configuration includes the perforated back panel and shelves. Hooks, end caps, and other accessories are optional and can be ordered separately based on display requirements.

Precautions

    Ensure the shelf is vertically aligned, and all adjustable feet are leveled and locked during installation.

    The perforated panel edges are ground smooth, but when installing hooks, align them properly with holes to avoid scratching the powder coating.

    For hanging items, keep the weight per hook within the manufacturer’s specified limit (typically 2-5 kg) to prevent hook deformation or hole enlargement.

    Distribute heavy items evenly across each shelf surface; avoid point loading.

    Clean with a soft cloth and mild detergent. Do not use steel wool or acidic solvents, which may damage the powder coating.
